| Model No. | EB-500 |
| Electromotor(wheel bone motor) | Permanent magnet brushless motor | BLDC |
| Rated Voltage | 48V |
| Rated Power | 500W |
| Controller | Protection Mechanisms | Current-limiting protection |
| Under voltage protection |
| Brake power-off protection |
| Brake short-circuit protection |
| Test hall fault protection |
| Control Mechanism | FOC |
| Transmission System | 7 Speeds |
| Sensor | Torque Sensor |
| Brake System | Front Wheel | Disk Brake System |
| Rear Wheel | Disk Brake System |
| Shock Absorbers(Front wheel) | yes |
| Tyre Size | 20*4.0 |
| Performance | Max. speed | 25km/Hr |
| Auxiliary Mileage ( Fully charged ) | 45km(ECO Auxiliary Mode) |
| Load Capacity | ≦150KG |
| Battery | Battery Type | Lithium Battery，Extractive |
| Capacity | 13Ah |
| Rated Voltage | 48V |
| Battery Charger | Input Voltage | AC 100 V ~ 240 V, 50/60Hz |
| Output Voltage | DC 54.6V |
| Output Current | 3A |
| Charge Time | About 5 hours |
| Frame Material | Aluminum alloy |
| Dimensions (L x W x H) | 1800 × 70 × 1110 mm |
| Wheelbase | 1227mm |
| Weight (excluding battery weight) | 27.5 |
| Weight (including battery weight) | 31.8kg |
